Fujitsu AOYG45LAT8 User Manual

2-3-4 Outdoor Unit Display
POWER
LED981
ERROR
LED982
MODE
EXIT
SELECT
ENTER
SW931
SW932 SW933
0.1sec 0.1sec
ON
ON
OFF
OFF
POWER MODE LED : on
ERROR LED : flashing
ERROR transition
"Err." and quantity are alternately shown.
When there is more than one error, display is changed by Press the "SELECT" button .
Press the "ENTER" button Press the "ENTER" button
Annunciation
Type of errors
Press the "SELECT" button
display change
If some error is newly occured or resolved
during transition, it is reflected after going
back to "Annunciation".
LED display
Operation button
ex : discharge thermistor 1 abnormal ex : indoor unit abnormal
02-11
LED981
LED962
LED961
POWER
MODE
ERROR
(GREEN)
LED982
(RED)
CHECK
SW934
