Fujitsu AOYG45LAT8 User Manual

Low noise operation
Defrost operation
Oil recovery operation
Heating mode
Error display mode
(Number of errors occured)
Error display mode
(Error code)
Error display for Check run
(Wiring number error)
Connected units display
(Only for Check run)
Error display for Check run
(Pipe number error)
Error display for Check run
(Wiring error)
Cooling mode
Idling(stop)
Indication type 7 Segment LED Pattern
Blank
"C" OO "L"
"H" EA "T"
"RUN"
"END"
"O" IL "R" ECOVERY
"D" E "F" ROST
"FAIL"
"P" OWER "OFF"
"C" HECK "RUN"
Number of Branch boxes
Number of Indoor units
"P" IPE ">" "L" INE
Blinking
Blinking
"P" IPE "<" "L" INE
"DONE"
"P" eak "C" ut
"L" OW "N" OISE
Description
Power saving operation
Running the vacuum/
pump down mode
Running Check.
Memory clear
Indeterminable
Performing function failed
Power off
Preparation display
End of the function
End of Check run
During Oil recovery operation.
Refer to 01-36 page for operation.
During Cooling mode
During Heating mode
During Defrost operation.
Refer to 01-33 page for operation.
During Power saving operation.
Refer to 01-40 page for operation.
During Low noise operation.
Refer to 01-40 page for operation.
Number of errors occured are displayed.
(Ex. Two error codes present.)
Refer to 02-11 page for details.
Error codes are displayed.
(Ex. Discharge thermistor error)
Refer to 02-11 page for details.
Vacuum/ Pump down mode running.
Wiring check in Check run is performing.
When "P.oFF" is displayed,
turn off the power supplies of all units.
Number of "8888" is displayed
for 2 minutes after power on.
Number "0000" is blinking for 1 minute
when the memory is cleared after Check run
is finished.
Wiring error has occured.
(Ex. Connection of Terminal A on the primary BB
to Terminal B on secondary 2 BB is wrong.)
The external or room temperature is outside
the operating range of Check run.
Number of wirings between indoor unit and
branch box is not correct.
Number of pipes between indoor unit and
branch box is not correct.
The function can not be performed.
The function is finished normally.
(Function is "Test-run start/ stop"
and "EEPROM memory clear".)
Check run is finished.
Alternating display
1st Branch box & terminal
2nd Branch box & terminal
ex.
ex.
ex.
ex.
02-11
+1
