FRONT VIEW
APPLICABLE MODEL：ALL MODEL
WIRE d
WIRE e
WIRE m(2 WIRES)
⑯
⑮
⑰
⑬
⑫
⑫
⑱
⑳
⑲
21
22
BIND (middle size)
WIRE d,e,m(2 WIRES)
BIND (middle size)
WIRE a(2 WIRES),b,c
⑭
BIND (middle size)
WIRE a(2 WIRES),b,c,d,e,m(2 WIRES)
Don't slack wires.
BIND (middle size)
WIRE a(2 WIRES),b,c,d,e,i(2 WIRES),j(2 WIRES),k,l,m(2 WIRES)
BIND (middle size)
WIRE k,l
BIND (middle size)
WIRE i(2 WIRES),j(2 WIRES)
BIND (middle size)
WIRE i(2 WIRES),j(2 WIRES),k,l
※NOT BIND WIRE g
BIND (middle size)
WIRE f-1,h-1(2 WIRES) (For AOU48RLXFZ)
WIRE f-1,h-2 (For AOBG45LAT8)
WIRE f-2,h-2 (For AOYG45LAT8,AOHG45LAT8,
ROG45LAT8,HOG45LAT8)
BIND (middle size)
WIRE g
WIRE f-1 (For AOU48RLXFZ,AOBG45LAT8)
WIRE f-2 (For AOYG45LAT8,AOHG45LAT8,
ROG45LAT8,HOG45LAT8)
Don't slack wires.
WIRE k
WIRE l
OPENED
WIRE g
※We have removed theRight panelwhen taking the pictures.
03-15
