13. Accessories

Part name Exterior Q’ty Part name Exterior Q’ty

Installation manual 1 Drain pipe 1

Drain cap 5

Adapter assembly,

1/2 (12.7)→3/8 (9.52)

[in (mm)]

Washe

dapter

- 245 -

13. Accessories

OUTDOOR UNIT

AOU24RLXFZ

OUTDOOR UNIT

AOU24RLXFZ
