CIRCUIT DIAGRAM
INDOOR UNIT
OUTDOOR UNIT
Models : AS*9LSACW / AO*9LSAC
AS*12LSACW / AO*12LSAC
Controller PCB
Thermistor
(pipe)
Thermistor
(discharge pipe)
Thermistor
(outdoor temp.)
