Fujitsu ASTG30KMTA User Manual

- 12 -
WALL MOUNTED ASTG30, 34KMTA
6. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
6-1. Cooling capacity
 Model: ASTG30KMTA
 Model: ASTG34KMTA
AFR
m
3
/h
1,400
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 6.25 5.14 0.75 6.96 5.17 0.76 7.20 5.62 0.76 7.67 5.64 0.77 7.91 6.09 0.77 8.39 6.07 0.78 8.86 6.46 0.79
0 6.16 5.09 0.80 6.86 5.12 0.81 7.10 5.56 0.82 7.57 5.58 0.83 7.80 6.03 0.83 8.27 6.00 0.84 8.74 6.40 0.85
5 6.13 5.05 0.85 6.83 5.08 0.87 7.07 5.53 0.87 7.53 5.55 0.88 7.77 5.99 0.88 8.23 5.96 0.89 8.70 6.35 0.90
10 6.11 5.02 0.90 6.80 5.05 0.92 7.04 5.49 0.92 7.50 5.51 0.93 7.73 5.95 0.94 8.20 5.93 0.95 8.66 6.31 0.96
15 6.65 5.27 1.25 7.41 5.31 1.27 7.67 5.77 1.28 8.17 5.79 1.29 8.42 6.25 1.30 8.93 6.22 1.31 9.43 6.63 1.32
20 7.20 5.53 1.60 8.02 5.56 1.62 8.30 6.05 1.63 8.84 6.07 1.65 9.12 6.55 1.65 9.66 6.52 1.67 10.21 6.95 1.69
25 6.95 5.41 1.79 7.74 5.45 1.82 8.00 5.92 1.83 8.53 5.94 1.85 8.80 6.41 1.86 9.32 6.39 1.88 9.85 6.81 1.90
30 6.63 5.20 2.08 7.39 5.23 2.12 7.64 5.68 2.13 8.14 5.70 2.15 8.40 6.16 2.16 8.90 6.13 2.18 9.40 6.53 2.20
35 6.72 5.29 2.37 7.48 5.32 2.41 7.74 5.79 2.42 8.25 5.81 2.45 8.50 6.27 2.46 9.01 6.24 2.48 9.52 6.65 2.51
40 5.56 4.77 2.08 6.20 4.80 2.11 6.41 5.22 2.12 6.83 5.23 2.14 7.04 5.65 2.15 7.46 5.63 2.18 7.89 6.00 2.20
46 4.74 4.47 2.11 5.28 4.50 2.15 5.46 4.89 2.16 5.82 4.91 2.18 6.00 5.30 2.19 6.36 5.28 2.21 6.72 5.62 2.23
AFR
m
3
/h
1,400
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 8.76 5.57 1.13 9.76 5.61 1.15 10.09 6.10 1.16 10.76 6.12 1.17 11.09 6.61 1.18 11.76 6.58 1.19 12.42 7.01 1.20
0 8.68 5.55 1.20 9.67 5.58 1.21 10.00 6.07 1.22 10.66 6.09 1.23 10.99 6.57 1.24 11.65 6.55 1.25 12.31 6.97 1.26
5 8.63 5.59 1.27 9.61 5.62 1.29 9.94 6.11 1.30 10.59 6.13 1.31 10.92 6.62 1.32 11.58 6.60 1.33 12.23 7.03 1.35
10 8.60 5.66 1.37 9.57 5.69 1.40 9.90 6.19 1.40 10.55 6.21 1.42 10.88 6.71 1.42 11.53 6.68 1.44 12.19 7.11 1.45
15 8.55 5.65 1.54 9.52 5.68 1.56 9.85 6.17 1.57 10.50 6.19 1.58 10.82 6.69 1.59 11.47 6.66 1.61 12.12 7.10 1.62
20 8.77 5.40 1.89 9.77 5.43 1.92 10.10 5.90 1.93 10.77 5.92 1.95 11.10 6.40 1.96 11.77 6.37 1.98 12.43 6.79 2.00
25 8.90 5.50 2.24 9.91 5.54 2.27 10.25 6.02 2.28 10.92 6.04 2.31 11.26 6.52 2.32 11.94 6.50 2.34 12.61 6.92 2.37
30 9.17 5.62 2.65 10.22 5.65 2.70 10.57 6.14 2.71 11.26 6.16 2.74 11.61 6.66 2.75 12.31 6.63 2.78 13.00 7.06 2.81
35 7.43 5.53 2.68 8.27 5.56 2.72 8.55 6.05 2.74 9.12 6.07 2.77 9.40 6.55 2.78 9.96 6.52 2.81 10.53 6.95 2.84
40 8.01 5.21 3.04 8.92 5.24 3.09 9.23 5.69 3.10 9.84 5.71 3.14 10.14 6.17 3.15 10.75 6.14 3.18 11.36 6.55 3.21
46 6.79 4.75 3.07 7.57 4.77 3.12 7.83 5.19 3.14 8.34 5.21 3.17 8.60 5.62 3.18 9.12 5.60 3.21 9.63 5.97 3.25
