Fujitsu ASTG30KMTA - 6. Additional charge calculation

- 58 -
OUTDOOR UNIT AOTG30, 34KMTA
6. Additional charge calculation
6-1. Model: AOTG30KMTA
 Refrigerant charge
6-2. Model: AOTG34KMTA
 Refrigerant charge
Refrigerant type R32
Refrigerant amount g 1,650
Total pipe length m 20 or less 30 40 50 (Max.)
40 g/m
Additional charge g 0 400 800 1,200
Refrigerant type R32
Refrigerant amount g 2,000
Total pipe length m 30 or less 40 50 (Max.)
45 g/m
Additional charge g 0 450 900
