6. SYSTEM DESIGN
CONTROLLER CABLE WIRING4-4.
WIRING SPECIFICATIONS

Model type Connection to Wire Cable size pecication
Central remote
controller
Branch box
Remote controller
cable
0.33 mm
2
Sheathed PVC cable Polar
3core
Wired Remote
Controller
Indoor unit
Remote controller
cable
0.33 mm
2
Simple Remote
Controller
Indoor unit
IR Receiver Unit Indoor unit Connection cable - (5m cable attached)
Caution
Install in accordance with local rules and regulations.
Never bundle the power supply cable and controller cable together. Bundling these cords together 
will cause misoperation.
Always ground the shilded cable at both ends.
For detail specification and connection, please refer to "5 Control system".
- (06 - 48) -
