Fujitsu ASYG12LZCA - Dimensions; Models: ASYG09 LZCA, ASYG12 LZCA, and ASYG14 LZCA

- 10 -
WALL MOUNTED ASYG09-14LZCA
4. Dimensions
4-1. Models: ASYG09LZCA, ASYG12LZCA, and ASYG14LZCA
Unit: mm
375
for pipe inlet Ø 65
for pipe inlet Ø 65
387
Outline of unit
470 470
270
43
295
295
940
940
387
83
77
393
40
9
43
