- 38 -
WALL MOUNTED
AOYG09-14LZCAN
1. Specifications
Type Inverter heat pump
Model name
AOYG09LZCAN AOYG12LZCAN AOYG14LZCAN
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 2.9 4.0 5.3
Fan
Airflow rate
Cooling
m
3
/h
1,350 1,680 2,050
Heating 1,840
Type × Q'ty Propeller fan × 1
Motor output W 115
Sound pressure level *1
Cooling
dB (A)
39 43 49
Heating 47 49
Sound power level
Cooling
dB (A)
52 57 61
Heating 58 59 61
Heat exchanger type
Dimensions
(H × W × D)
mm
588 × 881 × 36.4
Fin pitch 1.3
Rows × Stages 2 × 28
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance
Compressor
Type × Q'ty Rotary × 1
Motor output W 850 1,000
Refrigerant
Type (Global warming potential) R410A
Charge g 1,300 1,400
Refrigerant oil
Type FREOL α68SZ
Amount
cm
3
350
Enclosure
Material Steel sheet
Color
Beige
Approximate color of MUNSELL 10YR7.5/1.0
Dimensions
(H × W × D)
Net
mm
620 × 790 × 290
Gross 713 × 945 × 395
Weight
Net
kg
39 40
Gross 43
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4)
Gas Ø 9.52 (Ø 3/8) Ø 12.7 (Ø 1/2)
Method Flare
Pre-charge length
m
15
Max. length 20
Max. height difference 15
Operation range
Cooling
°C
-10 to 46
Heating -25 to 24
Drain hose
Material LDPE
Size mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.7 (O. D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/ 19 °CWB, and outdoor temperature of 35 °CDB/ 24 °CWB.
– Heating: Indoor temperature of 20 °CDB/ 15 °CWB, and outdoor temperature of 7 °CDB/ 6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
