Fujitsu ASYG12LZCA - Fan Performance; Air Velocity Distributions

- 16 -
WALL MOUNTED ASYG09-14LZCA
7. Fan performance
7-1. Air velocity distributions
 Models: ASYG09LZCA and ASYG12LZCA
Measuring conditions
Fan speed Operation mode
HIGH FAN
Top v ie w
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
Top v ie w
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Left & Right
Side view
Vertical airflow direction louver: Up
Horizontal airflow direction louver: Center
Side view
Vertical airflow direction louver: Down
Horizontal airflow direction louver: Center
2
1
0
1
2
Unit: m/s(m)
(m)
01234567
8
9
2.0
1.0
0.5
3
2
1
0
1
2
3
Unit: m/s
(m)
(m)
012345678
9
2.0
2.0
1.0
1.0
0.5
0.5
2.0
0.5
1.0
3
2
1
0
Unit: m/s
(m)
(m)
012345678
9
2.0
0.5
1.0
3
2
1
0
Unit: m/s
(m)
(m)
012345678
9
