Fujitsu AUU9RLF

¢
Maintenance space requirement
For future maintenance and service access, provide sufficient maintenance space.
NOTE: Do not place any wiring or illumination in the maintenance space, as they will impede ser-
vice.
Service access
Unit
Control
box
or more
Service space
12 (300)
12 (300) or more
4 (100)
or more
Unit: in (mm)
- 20 -
3-2. Slim duct type 3. Dimensions
MULTI TYPE 2, 3, 4 ROOMS TYPE MULTI TYPE 2, 3, 4 ROOMS TYPE
