16
Modular RAID Controllers
Modular RAID 3Gb/s (SAS1.0)
3.1.1 Features
●
3.3 V PCIe (PCI Express) add-in card
●
4 / 8-Port SAS / SATA
●
PCIe Interface x4 electrical, x8 mechanical
●
One / two Mini 4x SFF-8087 Multilane Connectors
●
3.0 Gbit/s and 1.5 Gbit/s link rates for both SAS and SATA
●
Integrated RAID (RAID 0, RAID 1, RAID 1E)
●
Supports SSP, SMP, STB, and SATA Protocols
●
Support of the following SATA II features:
– 3 Gbit/s SATA
– Staggered Spin-Up
– Hot Plug
– Native Command Queuing (NCQ)
●
Comes without, with standard, with low-profile bracket.
3.1.2 Controller versions
Name Chip No. of SAS
channels
Bracket type
S26361-D2507-B1x/D1x LSISAS1064e 4 low profile
full height
S26361-D2507-A1x/C1x LSISAS1068e 8 low profile
full height
