Modular RAID Controllers
33
Modular RAID 6Gb/s (SAS2.0)
4.1.2 Controller versions
4.1.3 Connectors and indicators
The following figure shows the location of the connectors and indicators on the
SAS RAID controller.
Name Chip
No. of SAS
channels
Bracket type
S26361-D2607-Ax LSI SAS2008 8
low profile
full height
1 HDD LED connector 3 SAS cable connectors
2LEDs
1
2
3
