Modular RAID Controllers
Modular RAID 12Gb/s (SAS3.0)
Indicators
5.2.4 Installation
This section describes how to install the SAS RAID controller in a server.
V CAUTION!
To safeguard against data loss, remember to back up your data before
you change your system configuration.
To install the new controller, proceed as follows:
LED Description
H322
(green blinking)
Heart Beat
H100 (orange) Fault LED
One surface mounted ORANGE LED (H100) indicates
FAULT condition. When LED is on, it indicates that
SuperCap pack is in FAULT condition.
H101 (blue) Activity (ONFI) LED
One surface mounted BLUE LED (H101) indicates activity
on ONFI interface. When LED is on, it indicates that either
Cache Offload from DDR3 memory to NAND Flash or
Restore Operation from NAND flash to DDR3 memory is in
progress.
H102 (green) Power LED
One surface mounted GREEN LED (H102) indicates the
status of back-up Power. When LED is on, it indicates that
SuperCap backup Power is enabled and SuperCap is
powering the controller when host system’s power is lost.
Once turned on this LED remains on during entire Cache
offload operation.
Step 1 Unpack the controller
Unpack the new controller in a static-free environment. Remove
it from the anti-static bag and inspect it for damage.
If the controller appears to be damaged, contact the Fujitsu
support service.
