Getting started
► Connect a connector of the data cable to the D-SUB socket or DVI-D socket or to the D P
socket of the monitor. Secure the plug-in connection by tightening the safety screws.
The m on itor automatically detects the input when only one signal source is conne cted .
► Insert one plug of the audio line in the AUDIO IN so cket on the monitor
and make sure it is properly engaged.
► Plug the power cable supplied into the power connecto r of the monitor.
A lock (Security Lock) can be mounted in the security slot to protect the monitor
against t heft. A Security Lock is not included with the monitor at delivery.
Connecting cables to the computer
Information on the compu ter connections and interfaces is contained in the
operating manual for your computer.
► Connect the data ca ble to the (active) monitor port on the computer and secure
the plug-in connection by tightening the safety screws.
► Insert the other plug of the audio cable in the audio output of the computer.
► Plug t he power connector of the monitor into a properly grounded mains outlet.
► Plug the power connector of the compute r into a properly grounded mains outlet.
If your computer has two monitor ports ("onboard" screen controller and separate
graphics card), the m onitor port for the s eparate graph ics card is active as sta ndard.
Fujitsu 17
