Getting started
Mounting the monito r base
► Install the base plate on the foot.
► Place the monitor in the operating position.
Adjusting the inclination
The inclination of the monitor can be adjusted by -3.5° (forwards) and +22°
(backwards) from its vertical position.
► Hold the monitor with b oth hands on the left and right sides of the casing
and move it to the desired angle.
Removing moni
tor base
Before you can use a swivel arm or a similar accessory, you must rem ove the monitor base.
The display surface is su sceptible to scratching!
2
1
► Switch off the monitor and pull the power
plug out of the po w er so cket.
► Lay the m onitor on its face on a soft surface.
► Disconnect all cables.
► Press the tab on the underside of
the base plate firmly inwards until it
disengages (1) and then pull the base
plate out of the foot (2).
14 Fujitsu
