Getting started
Connecting external devices
Read the documentation on the external device before connecting it.
With the exception of USB devices, always remove all power plugs
before con necting external devices!
Do not connect or disconnect cables d uring a thunderstorm.
Always take hold of the actual plug. Never unplug a cable by pulling the cable itself.
To ensure that your device works properly, only use the connection cable
supplied or only use a high-quality connection cable.
Ports on the device
Interf acesExternaldevices,Device,
The ports are located on the front and ba ck of the device. The ports available on your
device depe nd on the config uration level you have selected. The standard ports are
marked with the symbols shown below (or similar). Detailed information on the location
of the ports is provided in the manual for the ma inboard.
Headphones, black or light
green
Headphonesport
Audio input (Line In), light blue
AudioinputLineIn
Microphone port, black or pink
Microphoneport
Audio ou tput (Line Out), light green
AudiooutputLineOut
USB 3 .1 - Universal Serial Bus,
type A: blue, type C: black
UniversalSerialBus
USB 2.0 - Universal Serial Bus, type A,
black
USB 3 .1 Gen2 - Univers al
Serial Bus, type A: blue,
type C: black
PS/2 mouse port, gre en
MouseportPS/2mouseport
PS/2 keyboard port, purple
Keyboardport
DVI-D monitor port
DVI-Imonitorpor t
DP DisplayPort
DisplayPort
VGA monitor p ort, blue
Monitorport
LAN port
LANport
Serial port
Seria
linterface
Parallel port
Paral
lelport
Some o f the connected devices requ ire special drivers (see the
documentation for the connected device).
Fujitsu 15
