System expansio ns
Removing an M.2 module
Remove the casing cover (see chapter "Removing the casing cove r ", Page 32).
Fold ou t the drive cage (see chapter "
Opening the drive cage", Page 43).
a
b
b
1
2
Undo the screw o r t
he plastic holder (1).
Pull the M.2 module (b) slightly at an angle in the direction of the arrow (2) and out
of the s lot (a) on the mainboard and remove it from the c asing.
Fold the drive
cage into the closed position a gain (see chapter "
Closing the drive cage", Page 44).
Fit the casing cover onto the casing again (see chapter "
Reattaching the casing cover.", Page 33).
If necessary, you must adjust the entry for the M.2 module accordingly in the BIOS Setup.
Fujitsu 57
