Fujitsu ETERNUS Connection Guide

Chapter 3 Setting Up the Server
> 3.1 Creating a WWN Instance Management Table for the Server
ETERNUS Disk storage systems Server Connection Guide for Oracle Solaris
11
Copyright 2010 FUJITSU LIMITED
P3AM-4562-01ENZ0
4-2 Use the following command to check the WWN of the Fibre Channel card that
corresponds to the physical path name. The result is displayed in the same order as
shown in Step 4-1
.
Example
5 Add the results in the "WWN instance management table for the server".
Example
6 Check the controller number of the target connected to the Fibre Channel card.
6-1 Use the following command to check the controller number of the target connected to
the Fibre Channel card. The controller number corresponds to the physical path dis-
played in Step 4-1
.
Example
7 Add the results in the "WWN instance management table for the server".
End of procedure
This completes the "WWN instance management table for the server".
# prtpicl -v -c scsi-fcp | grep port-wwn
# prtpicl -v -c scsi-fcp | grep port-wwn
:bfa0-port-wwn 10:00:00:05:1e:e7:45:7b
:bfa1-port-wwn 10:00:00:05:1e:e7:45:7c
Physical slot name
WWN
Instance
name
Physical path name
Controller
name
bfa0
bfa1
/pci@7c0/pci@0/pci@8/bfa@0
/pci@7c0/pci@0/pci@8/bfa@0,1
PCIE1
PCIE2
100000051ee7457b
100000051ee7457c
# cfgadm -v
Ap_Id Receptacle Occupant Condition Information
When Type Busy phys_ID
c2 connected configured unknown
unavailable fc-fabric n /devices/pci@7c0/pci@0/pci@8/bfa@0/fp@0,0:fc
c3 connected configured unknown
unavailable fc-fabric n /devices/pci@7c0/pci@0/pci@8/bfa@0,1/fp@0,0:fc
Physical slot name
WWN
Instance
name
Physical path name
Controller
name
bfa0
bfa1
/pci@7c0/pci@0/pci@8/bfa@0
/pci@7c0/pci@0/pci@8/bfa@0,1
PCIE1
PCIE2
100000051ee7457b
100000051ee7457c
C2
C3
