Pin Signal Function
118
VCC18 1.8 V, regulated on XXSvideo-D for DDR2
SDRAM
119 TRACECLK Trace clock
120
VCC18 1.8 V, regulated on XXSvideo-D for DDR2
SDRAM
121 GND Ground at center pin
122 GND Ground at center pin
123 GND Ground at center pin
124 GND Ground at center pin
125 GND Ground at center pin
126 GND Ground at center pin
127 GND Ground at center pin
128 GND Ground at center pin
Tab. 2-2: Pin assignment of connector X201, I/O signals side
