1 Overview
1.1 Manual Scope
This manual provides detailed technical information about the EVB JADE-D Interface board for
system architects, hardware and software developers covering:
• System architecture description and users manual
• Hardware architecture
• Mechanical information
• References to further information like design data, data sheets, software documentation
It is the engineer’s reference for evaluation, system development and prototyping based on the
board. This document covers all available hardware versions regarding their configuration
options and revision state.
1.2 Putting into Operation
Plug the EVB JADE-D Interface board on a board only if the power supply is off !
