Pin Signal Description
1 AVIN2_RED Analog Red Signal
2 AVIN2_GREEN Analog Green Signal
3 AVIN2_BLUE Analog Blue Signal
4 NC Not connected
5 GND Ground
6 GND Ground
7 GND Ground
8 GND Ground
9 NC Not connected
10 GND Ground
11 NC Not connected
12 NC Not connected
13 AVIN2_HSYNC Horizontal Sync Signal
14 AVIN2_VSYNC Vertical Sync Signal
15 NC Not connected
Tab. 2-10: Pin assignment of connector X900
2.3 Hardware Variants
Prototypes have the version PA3.
For this revision PA4 hardware variants are not designated.
