4 - 11
CA
UTION
Do not look directly at the ligh
t source durin
g read operation.
Open the Document co
ver
.
Place the book f
ace down o
n the
Docume
nt bed.
Issue the
read command fr
om the host
system. K
eep the co
ver open
for the
reading opera
tion.
NO
TICE
Do not mov
e the book during the read operati
on.
Thick book
!
Reading a P
age from a Thic
k Book
46
48
