Fujitsu fi-4340C - Grounding Color Areas

● 5 - 7
The shaded area in the Figure below should have paper grounding color (white) or drop-out color. If not,
turn the white level following Off when reading.
3
Read reference
position
Grounding color (white
or drop-out color area
(Unit : mm)
Front Side
Scanning
direction
(sub)
Scanning
direction
(main)
Grounding Color Areas
