1
Chapter1 PREPARING THE SCANNER
1.1 Checking the Contents of
the Scanner Package
When you open the scanner package, please handle the
main unit and its attachments carefully.
Make sure it contains all the parts listed in the package
contents list that is included in the package box.
If any parts are missing or defective, contact the dealer
you purchased the scanner or an authorized Fujitsu scan-
ner service provider. Handle the scanner and accessories
with care.
1.2 Names and Functions of
Parts
This section describes the scanner parts and their func-
tions.
Front
[fi-5120C]
[fi-5220C]
Inside
[fi-5220C]
Rear
[fi-5120C]
[fi-5220C]
Automatic document
feeder (ADF)
ADF paper chute
Side guide
ADF button
Operator panel
Stacker
ADF (Automatic
document feeder)
ADF paper chute
Side guide
ADF button
Operator panel
Stacker
Flatbed
Document holding pad
Document cover
Document bed
Shipping lock
(located on base)
DC inlet
USB Interface connector
SCSI Interface connector
SCSI ID
switch
Security
Slot
