C120-H007-08EN 93
7.1 Protection of AC Line
(2) Install a surge absorber in each terminal outlet
Figure 7.1 shows the surge absorber connected to commercial power outlet. This type
is dedicated to single terminal. Applicable for all components using commercial
power outlet.
Figure 7.1 Surge absorber (power outlet connected type)
(3) Install a surge absorber to the input side of a distribution panel
Figure 7.2 shows the surge absorber installed on the input side of distribution panel.
All server systems in a group connected to the surge absorber mounted input line can
be protected.
Figure 7.2 Install surge absorber on the distribution panel's input side
To Next Page
