Fujitsu M10 Series - Free-Access Flooring; Table 2.2 Raised Floor Heights of Free-Access Floors

18 C120-H007-08EN
CHAPTER 2 Installation Sites
2.3.2 Free-access flooring
The construction of free-access floors is reviewed with respect to the following items:
 Raised floor height
 Strength and surface material of free-access floor panels
 Opening for server-system-use
 Installation of floor panels for a building air conditioner
Each item is described as follows:
(1) Raised floor height
Regarding the raised floor height of a free-access floor, the following factors require
consideration:
 Availability of underfloor ventilation
 Cabling height
 Safeguards against earthquakes
Table 2.2 lists suggested raised floor heights for free-access floors.
Table 2.2 Raised floor heights of free-access floors
Condition Raised floor height
Room
ventilation
Erected directly on the free-access floor
Optional earthquake-free legs that absorb the
energy of earthquakes installed to protect
against earthquakes
180 mm (7 in.) or higher
Clamped from under the free-access floor to
protect against earthquakes
250 mm (10 in.)
or higher
Underfloor
ventilation
Erected directly on the free-access floor
Optional earthquake-free legs that absorb the
energy of earthquakes installed to protect
against earthquakes
300 mm (12 in.)
or higher
Clamped from under the free-access floor to
protect against earthquakes
400 mm (16 in.)
or higher
