No. Part Function
1 Document cover Closes over and keeps in place the document to be read.
2 Document bed Holds document to be read. Also called Flatbed (FB).
3 Document holding pad Presses document to the Document bed.
4 Automatic document feeder
(ADF)
Automatically feeds documents to the reading position.
5 Stacker Stacks the read documents.
6 Operator panel Contains indicator panel that indicates scanner status.
7 Transport Lever Transport lever secures the carrier unit. Set to locked position
when moving scanner.
8 ADF paper chute Holds the documents to be fed by the automatic document
feeder (ADF).
9 ADF lever Opens/closes the ADF to enable the removal of documents
jammed in the feeder.
10 Power switch Turns the power On or Off.
11 Power inlet Connects to an AC power outlet with the power cable.
12 EXT connector Connects to an optional imprinter.
13 SCSI terminator switch Set to ON when the image scanner is the final device on the
SCSI daisy chain. Otherwise, set to OFF.
14 SCSI-ID switch Sets the SCSI ID. (Default ID is 5.)
15 SCSI Interface connectors Connect to the host system with SCSI interface cables.
16 Third party slot A Fujitsu VIDEO INTERFACE OPTION BOARD or
fi-475CMP3 (JPEG COMPRESSION BOARD) is installed.
17 Spare Pad ASSY Spare Pad ASSY. (One spare Pad ASSY is provided as the
default setting.)
18 Side giude Adjust the Side guide to match the width of the document to
avoid image skew.
19 USB interface connector Used for connecting a USB interface cable from a PC.
