Fujitsu M3093GX Cleaning And Maintenance

● 2
NOTE
The Shipping Lock should be switched to the operating position when the scanner is to be used. Refer to
"Operator’s Guide" for details of Shipping Lock.
(3) Document holding pad
(2) Document bed
(1) Document cover
(4) Automatic document
feeder (ADF)
(6) Operator panel
(5) Stacker
(7) Shipping Lock
(9) ADF lever
(16) Third party slot
(Option board slot)
(8) ADF paper chute
(10) Power switch
(11) Power Inlet
(15) SCSI Interface connector
(12) EXT connector
(17) Spare Pad ASSY
(14) SCSI ID switch
(13) SCSI terminator switch
(18) Side guide
(19) USB Interface connector
