Fujitsu M3093GX Cleaning And Maintenance

● 44
The termination should be
turned off by the SCSI
terminator switch on the rear
of the image scanner.
(When using SCSI)
Is the scanner the last
device of the SCSI chain?
YES
NO
Set the SCSI ID correctly.
Use the SCSI ID switch on
the rear of the image
scanner to change the ID.
(When using SCSI)
Is the SCSI ID set
correctly?
YES
NO
Contact the manufacturer’s
authorized service center to
set the correct baud rate.
Is the baud rate of the
system 4800 bps?
(When you use the Fujitsu
video interface board.)
NO
The image scanner is
operating normally.
Is the CHECK indicator lit?
Is an Alarm displayed?
NO
YES
YES
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
CHECK
Contact the manufacturer’s authorized
service center.
Turn off the power once
and then try to turn on the
power again. Is an Alarm
displayed ?
The Image Scanner is
operating normally.
YES
