RX1330 M1
Operating Manual 25
Functional overview
Onboard or integrated controllers
Serial (9-pin) 1 x serial RS-232-C, usable for iRMC or system or
shared
LAN / Ethernet (RJ-45) 1 x standard LAN, 1 x shared LAN
Management LAN
(RJ45)
1 x dedicated management LAN port for iRMC S4
(10/100/1000 Mbit/s); management LAN traffic can
be switched to shared onboard Gbit LAN port
RAID Controller Modular RAID 0/1 controller with "Integrated
Mirroring Enhanced" (SAS IME) for SAS1.0.
RAID levels 0, 1 and 1E are supported for internal
hard disk drive configurations.
Modular RAID 0/1 controller with “MegaRAID
functionality” (SAS MegaRAID) for SAS1.0 and
SAS2.0.
RAID levels 0, 1,10 and 1E are supported for internal
hard disk drive configurations.
Modular RAID 5/6 controller with "MegaRAID
functionality" (SAS MegaRAID) for SAS1.0 and
SAS2.0. RAID levels 0, 1, 10, 1E, 5, 50, 6 and 60 are
supported for internal hard disk drive configurations.
SATA Controller Intel
®
C226, 1 port used for accessible drive; 4 port
for internal SATA HDDs with RAID 0, 1, 10 for
Windows and Linux
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4), 256 MB DDR3-800 SRAM for video,
IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon TCG V1.2 compliant (option)
