Fujitsu PRIMERGY RX2540 M1 Operating Manual

RX2540 M1 Operating Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Concept and target groups for this manual . . . . . . . . . 12
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 12
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 13
2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Server specification . . . . . . . . . . . . . . . . . . . . . . 25
3 Installation steps, overview . . . . . . . . . . . . . . . . . . 33
4 Important information . . . . . . . . . . . . . . . . . . . . . 35
4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 35
4.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 43
4.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 44
4.4 Transporting the server . . . . . . . . . . . . . . . . . . . . 45
4.5 Notes on installing the server in the rack . . . . . . . . . . . 46
4.6 Environmental protection . . . . . . . . . . . . . . . . . . . 47
5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 49
5.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 50
5.2 Installing/removing the server in/from the rack . . . . . . . 51
5.3 Connecting devices to the server . . . . . . . . . . . . . . . 53
5.4 Connecting the server to the power source . . . . . . . . . 58
5.4.1 Connecting the server to the mains . . . . . . . . . . . . . . . 58
5.4.2 Using the cable clamp . . . . . . . . . . . . . . . . . . . . . . 59

Fujitsu PRIMERGY RX2540 M1 Specifications

General

Tcase	72.6 °C
Bus type	QPI
Stepping	R2
FSB Parity	No
Scalability	2S
Processor code	SR207
Processor cache	15 MB
Processor cores	6
Processor model	E5-2620V3
System bus rate	8 GT/s
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	12
Processor codename	Haswell
Execute Disable Bit	Yes
Motherboard chipset	Intel® C612
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor package size	52.5 x 45 mm
Processor front side bus	- MHz
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
PCI Express configurations	x4, x8, x16
Supported instruction sets	AVX
Thermal Design Power (TDP)	85 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
Maximum number of SMP processors	2
Maximum number of PCI Express lanes	40
Memory types supported by processor	DDR4-SDRAM
Memory channels supported by processor	Quad
Memory clock speeds supported by processor	1600, 1866 MHz
Memory bandwidth supported by processor (max)	59 GB/s
Maximum internal memory supported by processor	768 GB
HDD size	- \
RAID levels	0, 1, 5, 6, 10, 50, 60
Optical drive type	DVD Super Multi
Supported HDD sizes	3.5 \
Total storage capacity	- GB
Maximum storage capacity	- TB
Number of HDDs installed	-
Number of HDDs supported	4
Supported storage drive interfaces	SAS, Serial ATA
Memory slots	24
Internal memory	8 GB
Memory clock speed	2133 MHz
Maximum internal memory	1536 GB
Memory layout (slots x size)	1 x 8 GB
LAN controller	Intel I210
Cabling technology	10/100/1000Base-T(X)
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	5
PCI Express slots version	3.0
PCI Express x8 (Gen 3.x) slots	3
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 85 %
Certification	CB, RoHS, WEEE, GS, CE, CSAc/us, FCC, VCCI, KC, CCC, C-Tick, CNS
Power supply	450 W
Power supply input frequency	47 - 63 Hz
Chassis type	Rack (2U)
Operating system installed	Windows Server 2012 R2 Datacenter
Compatible operating systems	Windows Hyper-V Server 2012 R2 Windows Server 2012 R2 Datacenter Windows Server 2012 R2 Standard Windows Storage Server 2012 R2 Standard Windows Hyper-V Server 2012 Windows Server 2012 Datacenter Windows Server 2012 Standard Windows Hyper-V Server 2008 R2 Windows Server 2008 R2 Datacenter Windows Server 2008 R2 Enterprise Windows Server 2008 R2 Standard VMware vSphere 5.5 VMware vSphere 5.1 Embedded VMware vSphere 5.1 SUSE Linux Enterprise Server 11 Red Hat Enterprise Linux 7 Red Hat Enterprise Linux 6 Oracle Linux 7 Oracle Linux 6 Oracle VM 3
Processor ARK ID	83352
Intel Secure Key Technology version	1.00
Intel Identity Protection Technology version	0.00
On-board graphics card model	Not available

Weight and Dimensions

Depth	770 mm
Width	482.6 mm
Height	86.9 mm
Weight	25000 g
