Fujitsu PRIMERGY RX300 S8

System configurator and order-information guide
O
PRIMERGY RX300 S8 Status 2017-02-28
Section
X
Communication / Network
2x Gigabit (Dualport) Ethernet Contr.
Modular On-Board LAN is a flexible extension of a cost-optimized Motherboard
onboard
with basic 2x Gbit LAN on-board.
Intel LAN I350 (Powerville)
5 different Upgrade-Kits are offered, which occupies a dedicated PCIe slot and
ext: 2x RJ 45 connector
can be ordered once per system.
If a 1Gb modular LAN Controller is installed, 3 additional 1Gb LAN controllers are possible!
If a 10Gb modular LAN Controller is installed, 2 additional 10Gb LAN controllers is possible!
1Gbit/s Modular On-Board LAN Adapter
S26361-F4610-E802 S26361-F4610-E804 S26361-F3629-E702
Upgrade-Kit to 4x 1Gb LAN on-board LP Upgrade-Kit to 6x 1Gb LAN on-board LP
Upgrade-Kit to 2xGbit+2x10Gbit LOM
PLAN CP 2x1Gbit Cu Intel I350-T2 LP PLAN CP 4x1Gbit Cu Intel I350-T4 LP Eth Ctrl 2x10Gbit PCIe x8 D2755 SFP+
Intel Powerville based 2 port Server Ad. Intel Powerville based 4 port Server Ad. Intel Niantic based dual port 10Gb NIC
PCIe x4, Low Profile PCIe x4, Low Profile
please refer to 10Gb LAN section
ext: for RJ45-plug, Cat 5 ext: for RJ45-plug, Cat 5
max. 1x per system
max. 1x per system
4x 1Gbit/s Ethernet Adapter
S26361-F4610-E202 S26361-F4610-E204 S26361-F3516-E201
(I350-T2) (I350-T4) (Shelter Island)
Gbit Ethernet Controller Dual 1000TX LP Gbit Ethernet Controller Quad 1000TX LP Gigabit Ethernet Controller 1000TX LP
PLAN CP 2x1Gbit Cu Intel I350-T2 LP PLAN CP 4x1Gbit Cu Intel I350-T4 LP Eth Ctrl 1x1Gbit PCI-e Gigabit CT DT Cu LP
Intel Powerville based 2 port Server Ad. Intel Powerville based 4 port Server Ad. Intel® Gigabit CT Desktop Adapter
PCIe x4, Low Profile PCIe x4, Low Profile
PCIe x1
low profile (LP) bracket low profile (LP) bracket
ext: for RJ45-connector, Cat 5
ext: for RJ45-plug, Cat 5 ext: for RJ45-plug, Cat 5
max. 4x per system
max. 4x per system
max. 4x per system
Loose delivery with FH and LP bracket:
6x
I350-T2 S26361-F4610-L502
I350-T4 S26361-F4610-L504
Loose delivery with LP bracket:
Shelter Island S26361-F3516-L201
Sheepshead Bay
S26361-F3242-L201
P
Fujitsu PRIMERGY Server 25 of 31
