Fujitsu PRIMERGY RX300 S8

System configurator and order-information guide
PRIMERGY RX300 S8 Status 2017-02-28
P
If a 10Gb modular LAN Controller is installed, 1 additional 10gb LAN controllers is possible!
10GbE 2-Port SFP+ for MMF Module
10Gbit/s Ethernet Adapter
S26361-F3629-E702 S26361-F3629-E202 S26361-F3752-E202
(D2755)
(D2755)
(Intel X540-T2)
Upgrade-Kit to 2xGbit+2x10Gbit LOM
10 Gigabit Ethernet Contr. dual port SFP+
Eth Ctrl 2x10GBase-T lp
Eth Ctrl 2x10Gbit PCIe x8 D2755 SFP+ Eth Ctrl 2x10Gbit PCIe x8 D2755 SFP+ Intel Twinville based 2 port Server Ad.
Intel Niantic based dual port 10Gb NIC Intel Niantic based dual port 10Gb NIC
PCIe x4, Low Profile
PCIe x8, Low Profile, Low Profile Bracket PCIe x8, Low Profile, Low Profile Bracket
low profile (LP) bracket
ext: 2x SFP+ cage ext: 2x SFP+ cage ext: for RJ45-plug, Cat 6
max. 1x per system
max. 2x per system
max. 2x per system
S26361-F3629-E750
Shared 10Gb Management LAN
Install and configure Management
LAN on 10Gb Shared LAN port
max. 1x per 10Gb upgrade kit
S26361-F3986-E3 S26361-F3986-E4
V:TWX Connector-PY
SFP+ Module MMF 10GbE LC SFP+ Module SMF 10GbE LC for all Twinax (FTS,BR,CI)
SFP+ module for 10 Gbit SFP+ module for 10 Gbit
max. 2x per controller
Ethernet 50µm FO cabling
Ethernet 9µm FO cabling
ext:LC-SR-connector ext:LC-LR-connector
max. 2x per controller
max. 2x per controller
The SFP+ modules are also available as loose delivery
S26361-F3986-L3
S26361-F3986-L4
Instead SFP+ Modules, SFP+ twinax cables from the switch vendors may be used
S26361-F3989-E600 *) S26361-F3873-E500 *) S26361-F4571-E500 *)
*) in SA only
SFP+ active twinax cable SFP+ active twinax cable SFP+ passive twinax cable shown in
customized twinax cable for customized twinax cable for customized twinax cable for cabling view
full rack setup ex factory full rack setup ex factory full rack setup ex factory
cable length is selected by
cable length is selected by
cable length is selected by
requirement in the factory requirement in the factory requirement in the factory
Fujitsu branded cable
Brocade branded cable Cisco branded cable
max. 2x per controller
max. 2x per controller
max. 2x per controller
separate orderable 10Gb Ethernet cables
S26361-F3989-L102 SFP+ active Twinax Cable Fujitsu 2m
The controller D2755 is delivered without SFP+ modules for optical S26361-F3989-L105 SFP+ active Twinax Cable Fujitsu 5m
cables, these must be ordered separately.
S26361-F3989-L110 SFP+ active Twinax Cable Fujitsu 10m
Loose delivery options (FH and LP bracked included) S26361-F3873-L501 SFP+ active Twinax Cable Brocade 1m
D2755 S26361-F3629-L502 S26361-F3873-L503 SFP+ active Twinax Cable Brocade 3m
X540-T2 S26361-F3752-L502 S26361-F3873-L505 SFP+ active Twinax Cable Brocade 5m
S26361-F4571-L101 SFP+ passive Twinax Cable Cisco 1m
S26361-F4571-L103 SFP+ passive Twinax Cable Cisco 3m
S26361-F4571-L105 SFP+ passive Twinax Cable Cisco 5m
S26361-F4571-L107 SFP+ active Twinax Cable Cisco 7m
S26361-F4571-L110
SFP+ active Twinax Cable Cisco 10m
