Electrical data (hot-plug power supply unit)
*
Depending on PSU model inserted. Please, refer to your system`s rating plate.
Connection to the mains
The server is connected to the mains with 2 cords as a minimum or up to 4 cords
as a maximum for redundant operation. Each cord connection requires an
appropriate fuse in building installation (see above). Earthed socket outlets
have to be used (protection class I device).
Electrical ratings
*
100 – 240 V / 24 – 16 A or
200 – 240 V / 20 A
Frequency 50 Hz / 60 Hz
Current (basic configuration) 3.7 A (200 V)
Max. current 24 A / 16 A (100 V / 200 V)
Active power min. (typical configuration 1800 W
Active power max. (typical configuration) 1800 W
Apparent power (typical configuration) 1830 VA
Active power max. (max. configuration) 2100 W
Heat emmission 750 W = 2559 Btu/h
1800 W = 6142 Btu/h
2100 W = 7560 Btu/h
Main power fuse 16 A (200 - 240 V) or
20A (100 - 120 V)
Protection class I
