Fujitsu PRIMERGY TX1320 M3 User Manual

Operating Manual TX1320 M3
Contents
5.5 Notes on connecting/disconnecting cables . . . . . . . . . . 59
6 Starting up and operation . . . . . . . . . . . . . . . . . . . . 61
6.1 Access to the drives . . . . . . . . . . . . . . . . . . . . . . . 61
6.2 Opening the HDD cover . . . . . . . . . . . . . . . . . . . . . 63
6.3 Controls and indicators . . . . . . . . . . . . . . . . . . . . . 64
6.3.1 Server front . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
6.3.1.1 Controls on the front panel . . . . . . . . . . . . . . . . . . 64
6.3.1.2 Indicators on the front panel . . . . . . . . . . . . . . . . . . 65
6.3.1.3 Indicators on the drives . . . . . . . . . . . . . . . . . . . . 68
6.3.2 Server rear . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.3.2.1 Indicators on the I/O panel . . . . . . . . . . . . . . . . . . 70
6.3.2.2 Indicator on hot-plug PSUs . . . . . . . . . . . . . . . . . . 74
6.3.2.3 Indicator on Fujitsu battery units (FJBU) . . . . . . . . . . . 75
6.4 ID card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
6.5 Switching the server on and off . . . . . . . . . . . . . . . . 77
6.6 Configuring the server . . . . . . . . . . . . . . . . . . . . . 80
6.6.1 Configuring the onboard SATA controller . . . . . . . . . . . . . 80
6.6.2 Configuring the SAS/SATA RAID controller . . . . . . . . . . . . 81
6.6.3 Configuring the server and installing the operating system
with the ServerView Installation Manager . . . . . . . . . . . . . 82
6.6.4 Configuring the server and installing the operating system
without the ServerView Installation Manager . . . . . . . . . . . 83
6.7 Cleaning the server . . . . . . . . . . . . . . . . . . . . . . . 84
7 Property and data protection . . . . . . . . . . . . . . . . . . 85
7.1 Mechanical access protection . . . . . . . . . . . . . . . . . 85
7.2 BIOS Setup security functions . . . . . . . . . . . . . . . . . 85
8 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 87
8.1 Power-on indicator remains unlit . . . . . . . . . . . . . . . . 87
8.2 Server switches itself off . . . . . . . . . . . . . . . . . . . . 88
8.3 Screen remains blank . . . . . . . . . . . . . . . . . . . . . . 88

Fujitsu PRIMERGY TX1320 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
RAID levels	0, 1, 5, 6, 10
Storage drive sizes supported	2.5 \
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN	Yes
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Product color	Black, Red
Number of fans	1 fan(s)
Power supply	250 W

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
Weight	10000 g
