TX1320 M3 Operating Manual 23
Functional overview
2.2 Server specification
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
System Board
CPU
Memory Modules Configuration
System board type D3373
Chipset Intel
®
E3-1200V6 and Intel
®
C236
CPU quantity and type 1x Intel
®
Xeon
®
E3-1200 v6 (quad-core) / Pentium
®
/ Core™ i3
Memory slots 4
Memory slot type UDIMM (DDR4)
Memory capacity
(min. - max.)
4 GB - 64 GB
Memory protection ECC
Memory notes Dual channel support. For dual channel
performance, a minimum of 2 memory modules has
to be ordered. Capacity per channel has to be the
same. Memory modules with 4, 8 or 16 GB and 2400
MHz are available.

Fujitsu PRIMERGY TX1320 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
RAID levels	0, 1, 5, 6, 10
Storage drive sizes supported	2.5 \
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN	Yes
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Product color	Black, Red
Number of fans	1 fan(s)
Power supply	250 W

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
Weight	10000 g
