24 Operating Manual TX1320 M3
Interfaces
Onboard or integrated controllers
USB connectors 2.0 4x external rear, no USB wake-up supported
USB connectors 3.0 2x external front, no USB wake-up supported
2x external rear, no USB wake-up supported
1x internal for USB backup device
Graphics (15-pin) 1 x VGA
Serial 1 (9-pin) 1 x serial RS-232-C, usable for iRMC or system or
shared
LAN / Ethernet (RJ45) 2 x Intel
®
i210 Gbit/s Ethernet
Management LAN
(RJ45)
1 x dedicated service LAN port for iRMC S4
(10/100/1000 Mbit/s) Service LAN traffic can be
switched to shared onboard Gbit LAN port
RAID Controller Modular Host Bus Adapter with "Integrated RAID"
(IR). RAID levels 0 and 1 are supported for internal
HDD configurations.
Modular RAID 0/1 controller with “MegaRAID
functionality” (integrated MegaRAID). RAID levels 0,
1, 10, 5 and 50 are supported for internal HDD
configurations.
Modular RAID 5/6 controller with "MegaRAID
functionality" (MegaRAID). RAID levels 0, 1, 10, 5,
50, 6 and 60 are supported for internal HDD
configurations.
SATA Controller A 6-port SATA controller is integrated on the system
board; up to four SATA HDDs can be connected to
the controller. The LSI Embedded MegaRAID
software (SATA Software RAID) supports RAID
levels 0, 1 and 10.
Remote Management
Controller
Integrated Remote Management Controller
(iRMC S4), 256 MB DDR3-800 SRAM for video,
IPMI 2.0 compatible
Trusted Platform
Module (TPM)
Infineon V1.2 / V2.0 compliant (option)
