Fujitsu PRIMERGY TX1320 M3 User Manual

TX1320 M3 Operating Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1.1 Concept and target groups for this manual . . . . . . . . . . 9
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 10
1.3 Notational conventions . . . . . . . . . . . . . . . . . . . . 11
2 Functional overview . . . . . . . . . . . . . . . . . . . . . . 13
2.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2.2 Server specification . . . . . . . . . . . . . . . . . . . . . . 23
3 Installation steps, overview . . . . . . . . . . . . . . . . . . 31
4 Important information . . . . . . . . . . . . . . . . . . . . . 33
4.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 33
4.2 ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.3 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.4 FCC Class A Compliance Statement . . . . . . . . . . . . . 43
4.5 Environmental protection . . . . . . . . . . . . . . . . . . . 44
5 Hardware installation . . . . . . . . . . . . . . . . . . . . . . 47
5.1 Unpacking the server . . . . . . . . . . . . . . . . . . . . . 48
5.2 Setting up the server . . . . . . . . . . . . . . . . . . . . . . 49
5.2.1 Positioning the server vertically . . . . . . . . . . . . . . . . . 50
5.2.2 Positioning the server horizontally . . . . . . . . . . . . . . . . 53
5.3 Connecting devices to the server . . . . . . . . . . . . . . . 54
5.4 Connecting the server to the mains . . . . . . . . . . . . . . 56
5.4.1 Using cable ties (standard PSU) . . . . . . . . . . . . . . . . . 57
5.4.2 Using the cable clamps (hot-plug PSU) . . . . . . . . . . . . . 58

Fujitsu PRIMERGY TX1320 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
RAID levels	0, 1, 5, 6, 10
Storage drive sizes supported	2.5 \
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN	Yes
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Product color	Black, Red
Number of fans	1 fan(s)
Power supply	250 W

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
Weight	10000 g
