TX1320 M3 Operating Manual 25
Functional overview
Slots
Drive bays
Operating Panel
Slot 1: PCIe Gen3 x1
(mechanical x4)
up to 168 mm length, low profile
Slot 2: PCIe Gen3 x4
(mechanical x4)
notched, up to 168 mm length, low profile
Slots 3, 4: PCIe Gen3 x8
(mechanical x8)
notched, up to 168 mm length, low profile
Slot notes In SAS configuration 1x PCI-Express occupied by
modular RAID controller.
Hard disk bay
configuration
8x 2.5-inch hot-plug SAS/SATA or 2x 3.5-inch non
hot-plug SATA
Accessible drive bays 1x 3.5/1.6-inch for backup devices
Ultra Slim ODD
Notes accessible drives all possible options described in relevant system
configurator
Operating buttons Reset button
NMI button
ID button
On/Off button
Status LEDs ID indicator (blue)
CSS indicator (orange)
Global Error indicator (orange)
HDD/SSD activity indicator (green)
Power-on indicator (green)
AC connected indicator (green)

Fujitsu PRIMERGY TX1320 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
RAID levels	0, 1, 5, 6, 10
Storage drive sizes supported	2.5 \
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN	Yes
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Product color	Black, Red
Number of fans	1 fan(s)
Power supply	250 W

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
Weight	10000 g
