Fujitsu PRIMERGY TX1320 M3 User Manual

26 Operating Manual TX1320 M3
Functional overview
Dimensions / Weight
Ventilation clearance
At least 200 mm on the front and rear.
Ambient conditions
Condensation during operation must be avoided!
Upright operating
position (W x D x H)
193 mm x 438 mm x 360 mm (including feet)
Horizontal operating
position (W x D x H)
340 mm x 400 mm x 101 mm
Weight up to 11 kg
Weight notes Weight may vary depending on actual configuration
Environment class 3K2
Environment class 2K2
EN60721 / IEC 721 Part 3-3
EN60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 5°C ... 40°C (with ATD)
10°C ... 35°C (without ATD)
Transport (2K2) -25 °C ... 60 °C
Humidity 10% ... 85% (non condensing)

Fujitsu PRIMERGY TX1320 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
RAID levels	0, 1, 5, 6, 10
Storage drive sizes supported	2.5 \
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN	Yes
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Product color	Black, Red
Number of fans	1 fan(s)
Power supply	250 W

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
Weight	10000 g
