Fujitsu PRIMERGY TX1320 M3 User Manual

TX1320 M3 Operating Manual 27
Functional overview
Noise level
Noise level (detailed)
SATA systems
(4x 2.5" HDD,
standard PSU)
SAS systems
(8x 2.5" SAS HDD,
standard PSU)
Sound power level L
WAd
(ISO 9296)
3.3 B (standby)
3.5 B (operation)
4.3 B (standby)
4.7 B (operation)
Sound pressure level at
adjacent workstation L
pAm
(ISO 9296)
20 dB (A) (standby)
21 dB (A) (operation)
29 dB (A) (standby)
33 dB (A) (operation)
Declared noise emission
according to ISO 9296
Standby
Operating (ISO 7779)
ETSI 300 753 Class 3.1
LpAm at
bystander
position
A-weighted
sound
power level
L
WAd
Standby (fan control: standard) 20 dB (A) 3.3 B
Standby (fan control: performance), active with
INTEL LAN X540-T2 10 GB
30 dB (A) 4.5 B
Operation (OLTIS 100), depending on the
configuration
22 dB (A) 3.5 B
Standby (fan control: emergency) 26 dB (A) 4.2 B
High fan speed mode (8x 2.5" SAS HDD,
standard PSU)
48 dB (A) 6.2 B
High fan speed mode (8x 2.5" SAS HDD,
redundant PSU)
64 dB (A) 7.6 B

Fujitsu PRIMERGY TX1320 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
RAID levels	0, 1, 5, 6, 10
Storage drive sizes supported	2.5 \
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN	Yes
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Product color	Black, Red
Number of fans	1 fan(s)
Power supply	250 W

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
Weight	10000 g
