Fujitsu PRIMERGY TX1320 M3 User Manual

28 Operating Manual TX1320 M3
Functional overview
Electrical values of the PSU
Electrical values of the Fujitsu battery unit (FJBU)
Power supply
configurations
1 x standard PSU or 1x redundant PSU with two
hot-plug PSU modules
Max. output 250 W (standard PSU)
450 W (redundant PSU)
Rated voltage range 100 - 240 V
Rated frequency range 50 - 60 Hz
Rated current 5.0 A - 2.5 A (250 W, AC outlet included)
3 A - 1.5 A (450 W )
Main power fuse 16 A
Protection class I
Battery unit
configuration
1x hot-plug power supply and an FJBU inserted in
slot 2.
Max. output 280 W
Backup duration Max. 2 seconds (380W), 4 minutes (280W) with
FJBU M2
Charge duration 4 hours to 90%,5 hours to 100%
Battery spec. Nickel Metal-Hydrite battery
Battery life time 5 years
Input/Output voltage 12 V DC
Weight 1.2 kg
1x per system maximum

Fujitsu PRIMERGY TX1320 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
RAID levels	0, 1, 5, 6, 10
Storage drive sizes supported	2.5 \
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN	Yes
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Product color	Black, Red
Number of fans	1 fan(s)
Power supply	250 W

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
Weight	10000 g
