Fujitsu PRIMERGY TX1320 M3 User Manual

TX1320 M3 Operating Manual 67
Starting up and operation
iRMC-related status signals
6
AC
connected
indicator
green on
– The server is switched off and
connected to the mains
(standby mode).
– The server has been switched on
but Power Cycle Delay settings
delay it from turning on for a
specified time.
I After connecting the server to
the mains, it will take about
60 seconds until the server
will enter standby mode and
can be switched on.
off
– The server is switched off and
not connected to the mains.
– The server is switched on and
operating normally.
ID indicator
Global error
indicator
Description
blue flashing off
A remote connection has been
established. Local VGA output has been
disabled during the remote session.
blue flashing orange flashing
An emergency flash of the iRMC firmware
is in progress.
I For further information on the
emergency flash of the iRMC
firmware, refer to the "FUJITSU
Server PRIMERGY TX1320 M3
Upgrade and Maintenance
Manual".
Pos. Label Indicator Status Description

Fujitsu PRIMERGY TX1320 M3 Specifications

General

Processor socket	-
Built-in processor	No
Motherboard chipset	Intel® C236
Compatible processor series	Intel Core i3, Intel Pentium Dual-Core, Intel Xeon
Number of processors supported	1
Number of DIMM slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
RAID levels	0, 1, 5, 6, 10
Storage drive sizes supported	2.5 \
Supported storage drive types	HDD & SSD
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI (SAS)
Ethernet LAN	Yes
LAN controller	Intel I210
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet interface type	Gigabit Ethernet
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	2
PCI Express slots version	3.0
Product color	Black, Red
Number of fans	1 fan(s)
Power supply	250 W

Weight and Dimensions

Depth	399 mm
Width	98 mm
Height	340 mm
Weight	10000 g
