Fujitsu PRIMERGY TX1320 M4 - Product description; Overview of the server

TX1320 M4 Operating Manual 17
3 Product description
This section provides an overview of the server and information on the features
of the PRIMERGY TX1320 M4 server.
The PRIMERGY TX1320 M4 server can be used in a horizontal or a vertical
position.
3.1 Overview of the server
Figure 1: Server front - 2.5-inch variant
Pos. Component
1 4x 2.5-inch HDDs/SSDs SAS/SATA/PCIe
2 ID card slot
3 4x 2.5-inch HDDs/SSDs SAS/SATA
4 Accessible drives
5 Front panel module
6 Locking lever
