TX1320 M4 Operating Manual 93
8 Technical data
This section explains the specifications for the server. The specifications for this
server are liable to be updated without any notice. Please be forewarned.
I The data sheets for this server contain more technical data. The data
sheets are available online at:
http://www.fujitsu.com/fts/products/computing/servers/primergy
For more information, see the Documents tab under e.g. Rack Servers.
For Japan:
http://www.fujitsu.com/jp/products/computing/servers/primergy
System board
Memory modules configuration
System board type D3673
Chipset Intel
®
C246
Processor (CPU)
CPU quantity and type 1x Intel
®
Xeon
®
CPU 21xx or Pentium or Core i3 up
to 95W, up to 6 Cores
Memory slots 4
Memory type UDIMM (DDR4)
Memory capacity
(min. - max.)
4 GB - 64 GB
Memory protection ECC
Memory notes 2666 MHz memory modules with 4, 8 or 16 GB
