Fujitsu PRIMERGY TX1320 M4 - Controls and Indicators on the Server Front; Controls on the Front Panel

28 Operating Manual TX1320 M4
Product description
3.3.2 Controls and indicators on the server front
3.3.2.1 Controls on the front panel
Figure 5: Controls on the front panel module
Pos. Label Button Function
1 RESET Reset button
Reboots the system.
Press the reset button with a straightened
end of a paper clip.
V CAUTION!
Risk of data loss!
2 NMI NMI button
Used to troubleshoot software and device
driver errors.
Press the NMI button with a straightened end
of a paper clip.
V CAUTION!
Use this button only if directed to do so
by qualified certified maintenance
personnel!
3 ID ID button
Highlights the ID indicator on the front panel
and I/O panel for easy server identification.
