TX1320 M4 Operating Manual 81
Operation
6.3.2 Installing 3.5-inch HDD modules
I The 3.5-inch HDD modules are non-hot-plug SAS/SATA HDDs. For more
information, see the "FUJITSU Server PRIMERGY TX1320 M4 Upgrade
and Maintenance Manual".
6.4 Installing a second PSU
6.4.1 Removing the dummy cover
Figure 26: Removing the dummy cover
Ê Press in on both release latches (1) and remove the PSU dummy cover (2).
V CAUTION!
Keep the dummy cover for future use. If a PSU is removed and not
immediately replaced by a new one, a dummy cover must be installed in
the bay again to comply with applicable EMC regulations and satisfy
cooling requirements.
