88 Operating Manual TX1320 M4
Troubleshooting and tips
Time and/or date is incorrect
Cause Troubleshooting
Time and date is
incorrect
Ê Set the correct time and date in the operating
system.
or
Ê Set the correct time and date in the BIOS Main
menu, using System Date and System Time
respectively.
I Note that the operating system may affect the
system time. For example, the operating
system time may deviate from the system time
under Linux, and would overwrite the system
time in the default setting on shutdown.
The lithium battery is
discharged
Ê If the date and time are still wrong after the server
has been switched off and back on again, replace
the lithium battery (see the "FUJITSU Server
PRIMERGY TX1320 M4 Upgrade and
Maintenance Manual") or contact our customer
service team.
